Mitutoyo 513-454-10E (0.01mm) Vertical Type Dial Test Indicator 0.8mm

Product Description
£103.00 (ex VAT)
Delivery price: £5.99

Indicator Features:

  • Range: 0-0.8mm
  • Resolution: 0.01mm
  • Accuracy: ± 0.008mm
  • MPE any 10 scale divisions: ±0.005mm
  • MPE Measuring range: 0.008mm
  • Hysteresis: 0.003mm
  • Repeatability: 0.003mm
  • Scale: 0-40-0
  • Measuring Force: 0.3N or less
  • 8mm stem
  • Contact point thread: 1.75 x 0.35mm
  • MPN: 513-454-10E

This is a Dial Test Indicator (Lever Type) which offers you the following benefits:

  • Drastically enhanced durability, sensitivity and visibility.
  • Glare-free flat crystal face allows easy reading of graduations.
  • O-ring seal on the bezel has the effect of providing smooth rotation and prevents dust and oil from penetrating through to the dial face.
  • The stylus length is on the dial face to reorder a replacement
  • Multi-layer coatings on the crystal

Basic Set includes:

  • Knurled clamp ring
  • 8mm stem diameter
  • Stylus 2mm diameter carbide contact point
