Featured Products
3 Point Digital Bore micrometer
£264.00
Bore Micrometer Features Resolution: 0.001mm (0.00005") Accuracy: 0.003mm (0.00015") Sealed to IP54 standard Protected from water, coolant and oil splashes Completely protected from dust ingress Absolute or Incremental measurement Carbide measuring faces Extendable by 100mm mm-inch conversion Ratchet drive Setting ring (over 100mm not incl) Pow...
Digital Bore Micrometers 3 point 12-16mm ; 16-20mm ; 20-25mm | Resolution 0.001mm
Bore Gauges
Digital Bore Micrometers 3 point 12-16mm ; 16-20mm ; 20-25mm | Resolution 0.001mm
£245.00
Features: Resolution: 0.001mm IP54 protection level 150mm extension rod for measuring deeper bores Carbide-tipped contact points Supplied with setting ring Packed in aluminium box
Gauge Block Set Metric Steel 88 blocks
£270.00
Please select Grade and UKAS preference Delivery without UKAS 2-3days, with UKAS certificate: 1-2 weeks 88 piece set of excellent quality hardened steel gauge blocks each with unique serial number housed in a tailor made box with clear size markings. Stable dimensions with high accuracy and wringing force. Strictly made in accordance with DIN I...
Gauge Block Set Metric Steel 32 blocks
£109.00
Please select Grade and UKAS preference Delivery without UKAS 2-3days, with UKAS certificate: 1-2 weeks 32 piece set of excellent quality hardened steel gauge blocks each with unique serial number housed in a tailor made box with clear size markings. Stable dimensions with high accuracy and wringing force. Strictly made in accordance with DIN ...
Insize Digital Dial Indicator 2112 Series (Standard Type)
£167.00
Please select range, resolution and flat back or lug back before adding to basket Plunger clock type digital indicator. The dual-reading scale aids measurement in both directions, has a range of up to 12.7mm. Comes with optional SPC cable data output. Economic model. Button function: on/off, inch/mm, zero. CR2032 battery, automatic power off. U...
Insize 2103 Series Digital Dial Indicator with Rotating Display
£217.00
Reading in digit and analogue. Display can be rotated by 320 deg . Functions: tolerance GO and NO GO display, data pre-set, measuring direction change, max./min./range measurement, inch/metric conversion, absolute/incremental measurement. CR2032 battery, automatic power off. USB data output. Optional accessory: SPC cable, backs , contact points...
Waterproof Digital Dial Indicator | Insize 2115 Series | Range 12.5mm/0.5" | Resolution 0.01mm/0.005"
Dial Indicators
Waterproof Digital Dial Indicator | Insize 2115 Series | Range 12.5mm/0.5" | Resolution 0.01mm/0.005"
£96.00
Functions ON/OFF mm/inch Zero DATA (when connected with a dataconnection cable) Features Suitable for static measuring Data output via USB or RS232C,optional cable required Digital display Auto power off IP54 or IP65 waterproof Supplied with manufacturers calibration certificate
Insize Digital Micrometer up to 100mm
£66.00
Features: Resolution 0.001mm/0.00005" Button function: on/off, set, mm/inch, ABS/INC Without data output SR44 or LR44 battery, automatic power off Carbide measuring faces Ratchet thimble Supplied with spherical anvil Setting standards are included(except 0-25mm/0-1")
Insize Digital Height Gauge 0-300mm/0-12"
£300.00
The 1150 Digital Height Gage is made of stainless steel for longer tool life and durability from machine shop wear. With optional SPC cable data output. Sizes range from 0-300mm/0-12". Range of 300mm/12". Resolution 0.01mm/0.0005". Buttons: on/off, mm/inch, ABS/INC, hold, TOL, set. Carbide tipped scriber. Made of stainless steel (except base). ...
Insize Setting Rings 1.55 - 300mm
£168.00
Calibration setting ring, for quick and accurate setting of bore gauges, micrometers etc. For zero setting of inside micrometers, three points internal micrometers and bore gauges. Uncertainty in the diameter calibration value: ±1.5µm for ü2-100mm ±2.5µm for 125-200mm. Cylindricity: 1µm for ü2-60mm 1.5µm for 62-90mm 2µm for 100-200mm. DIN2250-1...
Steel Pin Gauge Sets Class ZZ (0.01mm increments)
£182.00
Features: Accuracy +/-0.001mm Pins 50mm long Increments 0.01mm Each pin size etched Each pin in a marked holder In a clearly marked wooden box Fully hardened to 60/62 HRC Certificate of conformity UKAS cert and handle optional
Granite Surface Plate (6900 Series) Grade 0
£189.00
Please email us to purchase this product. Due to weight and size, these are ordered direct from supplier and shipping cost will be quoted on enquiry. Surface Plate Features: Made of granite, free from deterioration or dimensional change overtime, minimal changes in dimension due to temperature changes. Meet DIN876, grade 00 is for inspection r...
