Mahr MarCal 30 EWRi Digital Depth Gauge 0-150mm/0-6"

Product Description
£440.10 (ex VAT)
Usually ships in: 2-3 days
Delivery price: £5.99 Delivery price: £17.00 Delivery price: £17.00
  • High contrast digit display
  • Locking screw above
  • Lapped guideway
  • Measuring surfaces made of steel
  • Slide and beam made of hardened stainless steel
  • Immediate measurements due to the Reference System
  • Raised guideway for the protection of the scale
  • Excellent resistance against dust, coolants and lubricants
  • Dirt wipers are integrated in the slide
Measuring range mm 0 - 150
Measuring range inch 0 - 6"
Resolution mm/inch 0.01 / .0005"
Error limit (mm) 0.03 mm
Error limit inches .001"
Standard ISO 13385-2
Battery type CR 2032 (3V Lithium)
Dimensions a 234 mm | b 100 mm |
