Mahr Micromar 45 T Depth Micrometer 0-100 mm

Previous Product | Next Product

Product Description

£357.30 (ex VAT)

Please email us for shipping times

Delivery price: £5.99 Delivery price: £17.00

Operating and display units with satin chrome finish
Stainless spindle is hardened throughout and ground
Rapid drive with integrated ratchet
Depth measurement
Measuring the space between grooves and groove widths in conjunction with a disc anvil 45 Tm

Standard	Factory standard
Measuring range mm	0 - 100
Graduation value mm	0,01
Error limit µm	5 µm
Notes error limit	Length tolerance of the extension +/-1,5 µm
Spindle diameter	4 mm
Spindle thread pitch_mm	0.5 mm
Dimensions	a 100 mm \| b 16 mm \| c 13 mm \|
