DRO ME-HG-600 Digital Digital Height Gauge Pro Series 600mm (24 inch)

Product Description
$306.00 (ex VAT)
Usually ships in: 2-3 days
Delivery price: £8.99

The Pro Series 600mm (24 inch) range Scribing offers functions such asInch/Metric Conversion, On/Off, Auto Power Off, Zero Setting, Low Battery Alert. Along with the advanced functions of Preset Value, Hold, Tolerance, ABS/INC. The height gauge has a Hardened Stainless Steel Column and Ergonomic Cast Iron Base. With a Fine Adjust Thumb Wheel to control the slider movement and Thumb Screw.

Range: 600mm (24 inch)

Resolution: 0.01mm (0.0005inch)

Accuracy: 0.05 mm (0.002inch)

Slider Adjustment: Fine Adjust Thumb Wheel

Scribe: Carbide

Battery Type: SR44

Data Output: No



  • 600mm (24 inch) range Pro Series Digital Scribing
  • 0.01mm (0.0005inch) resolution. 0.05mm (0.002inch. ) accuracy
  • Conforms to Factory/Manufacturers Standard
  • Conforms to Factory/Manufacturers Standard
  • With Hardened Stainless Steel Column and Ergonomic Cast Iron Base
  • Fine Adjust Thumb Wheel to control the slider movement and Thumb Screw
  • Carbide scriber tip
  • Functions; Inch/Metric Conversion, On/Off, Auto Power Off, Zero Setting, Low Battery Alert
  • Advanced functions; Preset Value, Hold, Tolerance, ABS/INC

  •
